Follow-up Form for Bearing Monitoring
The follow-up form is a necessary aid for systematic
condition monitoring. The development of the read-
ings over a period of time is a much better basis for
the planning of repairs and maintenance than the
result from a single reading.
The follow-up form provided by SPM has the ordering
number FUP-02 (metric units) or FUP-04 (imperial units).
It has space for two shock pulse measuring points and
one vibration measurement point. 15 readings for
each point can be recorded and plotted. A separate
follow-up form, consisting of one or several sheets,
should be prepared for each machine unit.
The fields on the form sheet are described in fig. 20.
The lower part of the follow-up form, intended for
vibration monitoring, is described in Part 4. The last
pages of this manual contain follow-up forms which
can be copied.
Fig. 20
Follow-up Form for
Shock Pulse Readings
1 Machine unit: name, number, location
2 Simple sketch showing the location and
number of each measuring point
3 Space for notes, instructions
4 Measuring point number
5 Measuring date
6 NORM, TYPE, COMP No.
7 Plotted COND numbers
8 Plotted LUB numbers.
