P340 flexiprobe Operation Manual 11
4.3.2 Focusing the cameras
The camera focus is adjustable and should be set to match the internal diameter of the pipe under
inspection.
With reference to Tables 4.1 and 4.2, place the camera at the required distance from a target object to get
optimal image quality.
Use the focus tool provided with the camera to turn the focusing ring until the target object is in focus.
1" (25mm) Camera
Internal Pipe
Diameter
Target Object
Inches
mm
Inches
mm
1.25
32
3.0
76
1.5
38
3.6
92
2
51
4.8
122
3
76
7.2
183
4
102
9.6
244
Table 4.1: 1” Camera focusing table
2" (50mm) Camera
Internal Pipe
Diameter
Target Object
Inches
mm
Inches
mm
2
51
5.6
142
3
76
8.4
213
4
102
11.2
284
6
152
16.8
427
8
203
22.4
569
9
229
25.2
640
Table 4.2: 2” Camera focusing table
4.3.3 Flexisondes and solid sonde
Pearpoint sondes allow location of the camera as it navigates a pipe using a Radiodetection locator, such
as the RD7000+DL.
The flexisonde (built-in on the P341 Plumbers reels) fits between the pushrod and the camera, allowing the
system to better negotiate bends in the pipe.
The solid sonde adds extra rigidity to the camera and it is ideal for “long push” inspections. A solid sonde
can be used in conjunction with a universal flexi.
4.3.4 Universal flexi
When fitted to the pushrod and camera, the universal flexi allows the camera and pushrod to negotiate
sharp bends in the pipe (not required for the Plumbers system).
