P340 flexiprobe Operation Manual 60
Observation popup
When entering observations, you can set up the controller to display, if recording, the observation you
have just entered automatically in the middle of the screen for duration of 4 seconds when resuming your
survey.
To enable this setting, go to MENU > SETUP > CONTROLLER > RECORDING > VIDEO TITLES and
set the Observation field to “on”.
9.8 Other Comments (Freetext)
If free-form text entry is required, from the Job Reviewer window use the arrows to select ‘Free Text’. This
allows space for up to 468 characters. This is particularly useful for notes or explanations that do not fit
elsewhere in the report.
Freetext fields
1. Title: use this field to give your comments a title. In the report, the title appears as a subheading
under the Comments page title (30 characters maximum).
2. Body: use this field to write your comments (468 characters maximum).
9.9 Condition code lists
By default the P340 controller has a built-in WRC MSCC 3 Condition Codes list, helping you, when you
enter an observation, to save time and ensure consistency.
The Condition Codes list is also available to browse and use when you edit text pages.
Custom Condition Codes list
You can change the built-in defect code list, for example by replacing it with the PACP defect code list or
just to customize it to better suit your specific needs. See the FlexiSight Manager user guide.
9.10 HTML Report
The P340 controller can provide a simple HTML report for each survey. This includes client, site and
survey details that are entered and any observation details added during the job.
HTML reports are compatible with most web browsers. You can view or print HTML reports using a
computer, by accessing the report.html file in the report folder for any survey on the storage device. See
Figure 9.6.
To create an HTML report, go to the Job Reviewer, move the cursor to the bottom half of the screen and
