P340 flexiprobe Operation Manual 37
6.6 Digital image controls
The P340 controller offers sophisticated digital imaging control to allow you to manipulate the video
displayed on the screen when playing back a recording or displaying a video from an external video source.
Pan
You can use the pan function to digitally pan a zoomed-in picture on screen.
1. To pan left press Fn and simultaneously, to pan right press Fn and simultaneously.
2. To reset the digital pan, simultaneously press Fn and and simultaneously.
Rotate
You can use the rotate function to digitally rotate the picture on screen.
1. Press or to digitally rotate the picture clockwise or anti-clockwise.
2. To reset the digital rotate, press and simultaneously.
Zoom
1. To zoom in press . To zoom out press .
2. To reset the zoom to x1 magnification, press and simultaneously.
6.7 Retrieving the camera
Once you complete the inspection, wind the reel to retrieve the camera from the pipe.
WARNING! Foul water systems can be a source of biological hazards. Maintain high sanitary
standards at all times. Clean the system after each inspection with a cloth soaked in a suitable disinfectant.
Always wear appropriate protection when conducting an inspection and when handling the P340.
1. Release the brake.
2. Layer the pushrod onto the reel by a combination of rotating the reel and pushing the pushrod
onto the reel. Do not simply rotate the reel.
NOTE: Evenly layer the rod onto the reel or the counter may give inaccurate readings.
3. Clean the rod and camera as required.
