1
1
7
7
-
-
6
6
2
2
9
9
5
5
0
0
5
5
X
X
B
B
D
D
i
i
g
g
i
i
t
t
a
a
l
l
I
I
n
n
t
t
e
e
r
r
f
f
a
a
c
c
e
e
R
R
e
e
p
p
l
l
a
a
c
c
e
e
m
m
e
e
n
n
t
t
• Follow instruction #2 for removal of the rear connector panel.
• Remove the pan Pozi screws holding the 629505XB assembly in to the 629505XA CPU.
• Disconnect loom P.
• Remove the screws from the AES and S/PDIF connectors on the rear panel.
• Remove the faulty assembly and transfer the plastic pillar to the replacement part.
•
Fit the new assembly and reassemble.
Appendix G - Service
135
Matrix Owner’s Manual
