Debug support (DBG) RM0008
1083/1128 DocID13902 Rev 15
31.8.6 SW-AP registers
Access to these registers are initiated when APnDP=1
There are many AP Registers (see AHB-AP) addressed as the combination of:
• The shifted value A[3:2]
• The current value of the DP SELECT register
01 Read/Write 0
DP-
CTRL/STAT
Purpose is to:
– request a system or debug power-up
– configure the transfer operation for AP
accesses
– control the pushed compare and pushed
verify operations.
– read some status flags (overrun, power-
up acknowledges)
01 Read/Write 1
WIRE
CONTROL
Purpose is to configure the physical serial
port protocol (like the duration of the
turnaround time)
10 Read
READ
RESEND
Enables recovery of the read data from a
corrupted debugger transfer, without
repeating the original AP transfer.
10 Write SELECT
The purpose is to select the current access
port and the active 4-words register window
11 Read/Write
READ
BUFFER
This read buffer is useful because AP
accesses are posted (the result of a read AP
request is available on the next AP
transaction).
This read buffer captures data from the AP,
presented as the result of a previous read,
without initiating a new transaction
Table 225. SW-DP registers (continued)
A(3:2) R/W
CTRLSEL bit
of SELECT
register
Register Notes
