DocID13902 Rev 15 170/1128

RM0008 General-purpose and alternate-function I/Os (GPIOs and AFIOs)

195

FSMC_NWAIT

FSMC_CD

Input floating/ Input pull-up

FSMC_NIOS16,

FSMC_INTR

FSMC_INT[3:2]

Input floating

FSMC_NL

FSMC_NBL[1:0]

Alternate function push-pull

FSMC_NIORD, FSMC_NIOWR

FSMC_NREG

Alternate function push-pull

Table 33. Other IOs

Pins Alternate function GPIO configuration

TAMPER-RTC pin

RTC output

Forced by hardware when configuring the

BKP_CR and BKP_RTCCR registers

Tamper event input

MCO Clock output Alternate function push-pull

EXTI input lines External input interrupts Input floating / input pull-up / input pull-down

Table 32. FSMC (continued)

FSMC pinout GPIO configuration
