Page #280 background imageLoading...
Page #280 background image
DocID13902 Rev 15 280/1128
RM0008 Direct memory access controller (DMA)
291
13.3.6 Interrupts
An interrupt can be produced on a Half-transfer, Transfer complete or Transfer error for
each DMA channel. Separate interrupt enable bits are available for flexibility.
Note: In high-density and XL-density devices, DMA2 Channel4 and DMA2 Channel5 interrupts
are mapped onto the same interrupt vector. In connectivity line devices, DMA2 Channel4
and DMA2 Channel5 interrupts have separate interrupt vectors. All other DMA1 and DMA2
Channel interrupts have their own interrupt vector.
13.3.7 DMA request mapping
DMA1 controller
The 7 requests from the peripherals (TIMx[1,2,3,4], ADC1, SPI1, SPI/I2S2, I2Cx[1,2] and
USARTx[1,2,3]) are simply logically ORed before entering the DMA1, this means that only
one request must be enabled at a time. Refer to Figure 50: DMA1 request mapping.
The peripheral DMA requests can be independently activated/de-activated by programming
the DMA control bit in the registers of the corresponding peripheral.
Table 77. DMA interrupt requests
Interrupt event Event flag Enable Control bit
Half-transfer HTIF HTIE
Transfer complete TCIF TCIE
Transfer error TEIF TEIE
