Direct memory access controller (DMA) RM0008

281/1128 DocID13902 Rev 15

Figure 50. DMA1 request mapping

Fixed hardware priority

Channel 3

internal

HW request 3

High priority

Low priority

Peripheral

Channel 2

HW request 2

Channel 1

SW trigger (MEM2MEM bit)

Channel 1 EN bit

HW request 1

Channel 4

HW request 4

DMA1

Channel 5

HW request 5

Channel 6

HW REQUEST 6

Channel 7

HW request 7

request

ADC1

USART1_TX

TIM1_CH4

SPI1_TX

USART3_TX

USART1_RX

TIM1_UP

I2C1_TX

TIM3_CH1

I2C1_RX

TIM2_CH2

SPI1_RX

TIM1_CH2

TIM4_CH3

TIM2_CH1

SPI/I2S2_TX

I2C2_RX

USART2_RX

TIM3_TRIG

TIM1_CH3

USART2_TX

TIM2_CH4

TIM4_UP

SPI/I2S2_RX

I2C2_TX

TIM1_TRIG

TIM4_CH2

TIM3_CH4

TIM3_UP

USART3_RX

TIM3_CH3

TIM1_CH1

TIM2_UP

TIM2_CH3

TIM4_CH1

Channel 2 EN bit

Channel 3 EN bit

Channel 4 EN bit

Channel 5 EN bit

Channel 6 EN bit

Channel 7 EN bit

SW trigger (MEM2MEM bit)

SW TRIGGER (MEM2MEM bit)

SW trigger (MEM2MEM bit)

request signals

TIM1_COM
