DocID13902 Rev 15 460/1128

RM0008 General-purpose timers (TIM9 to TIM14)

460

Refer to Table 3 on page 51 for the register boundary addresses.

0x18

TIMx_CCMR1

Output compare

mode

Reserved

OC1M

[2:0]

OC1PE

OC1FE

CC1S

[1:0]

Reset value 00000 0 0

TIMx_CCMR1

Input capture

mode

Reserved

IC1F[3:0]

IC1

PSC

[1:0]

CC1S

[1:0]

Reset value 000000 0 0

0x1C

Reserved

0x20

TIMx_CCER

Reserved

CC1NP

Reserved

CC1P

CC1E

Reset value 000

0x24

TIMx_CNT

Reserved

CNT[15:0]

Reset value 000000000000000 0

0x28

TIMx_PSC

Reserved

PSC[15:0]

Reset value 000000000000000 0

0x2C

TIMx_ARR

Reserved

ARR[15:0]

Reset value 000000000000000 0

0x30 Reserved

0x34

TIMx_CCR1

Reserved

CCR1[15:0]

Reset value 000000000000000 0

0x38 to

0x4C

Reserved
