Controller area network (bxCAN) RM0008

679/1128 DocID13902 Rev 15

CAN receive FIFO mailbox identifier register (CAN_RIxR) (x=0..1)

Address offsets: 0x1B0, 0x1C0

Reset value: 0xXXXX XXXX

All RX registers are write protected.

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

STID[10:0]/EXID[28:18] EXID[17:13]

rrrrrrrrrrrrrrrr

1514131211109876543210

EXID[12:0] IDE RTR

Res.

rrrrrrrrrrrrrrr

Bits 31:21 STID[10:0]/EXID[28:18]: Standard identifier or extended identifier

The standard identifier or the MSBs of the extended identifier (depending on the IDE bit

value).

Bits 20:3 EXID[17:0]

: Extended identifier

The LSBs of the extended identifier.

Bit 2 IDE: Identifier extension

This bit defines the identifier type of message in the mailbox.

0: Standard identifier.

1: Extended identifier.

Bit 1 RTR

: Remote transmission request

0: Data frame

1: Remote frame

Bit 0 Reserved, must be kept at reset value.
