5 | Technical data STOBER
28
03/2020 | ID 442793.03
5.2 DC link connection
The following section contains specifications for the electrical data, dimensions and weight of the DL6B modules Quick
DC-Link.
5.2.1 General technical data
The following information applies to all Quick DC-Link modules and corresponds to the general technical data for the base
device.
Device features
Protection class of the device IP20 (if built over with drive controller)
Protection class
Protection class I in accordance with DIN EN 61140 (if built over with drive
controller)
Protection class of the installation space At least IP54
Tab. 30: Device features
Transport and storage conditions
Storage/
transport temperature
−20°C to +70°C
Maximum change: 20K/h
Relative humidity Maximum relative humidity 85%, non-condensing
Vibration (transport) in accordance with
DIN EN60068-2-6
5Hz ≤ f ≤ 9Hz: 3.5mm
9Hz ≤ f ≤ 200Hz: 10m/s²
200Hz ≤ f ≤ 500Hz: 15m/s²
Fall height for freefall
2
Weight < 100kg
in accordance with DIN EN61800-2
(or DIN EN 60721-3-2:1997, class2M1)
0.25m
Tab. 31: Transport and storage conditions
Operating conditions
Surrounding temperature during
operation
0°C to 45°C with nominal data
45°C to 55°C with derating −2.5%/K
Relative humidity Maximum relative humidity 85%, non-condensing
Installation altitude
0m to 1000m above sea level without restrictions
1000m to 2000m above sea level with −1.5%/100m derating
Pollution degree Pollution degree 2 in accordance with EN 50178
Vibration (operation) in accordance with
DIN EN 60068-2-6
5Hz ≤ f ≤ 9Hz: 0.35mm
9Hz ≤ f ≤ 200Hz: 1m/s²
Tab. 32: Operating conditions
5.2.2 Assignment of DL6B to SC6
DL6B is available in the following designs suitable for the individual types:
Type DL6B10 DL6B11
ID No. 56655 56656
SC6A062 X —
SC6A162 — X
SC6A261 — X
Tab. 33: Assignment of DL6B to SC6
2
Only valid for components in original packaging
