7.6 Installing the drive controller without a rear section
module
This chapter describes the installation of the SC6 drive controller without a rear section module. If you would like to
connect the drive controllers in the DC link, you must mount the required rear section modules first, then build the
appropriate drive controllers over them.
WARNING!
Electrical voltage! Risk of fatal injury due to electric shock!
▪ Always switch off all power supply voltage before working on the devices!
▪ Note the discharge time of the DC link capacitors in the general technical data. You can only determine the absence
of voltage after this time period.
Information
Note that drive controllers in storage require reforming each year or before commissioning at the latest.
Tools and material
You will need:
§ Fastening screws
§ Tool for tightening the fastening screws
Requirements and installation
Perform the following steps for each drive controller within the group and in the specified order.
ü
In accordance with the drilling diagram, taking into consideration the various device dimensions, you have made
threaded holes for the threaded bolts on the mounting plate at the mounting position.
ü
The mounting plate has been cleaned (free of oil, grease and swarf).
1. Fasten the top of the drive controller on the mounting plate.
2. Fasten the bottom of the drive controller on the mounting plate.
3. Connect the grounding conductor to the ground bolt. Note the instructions and requirements in the chapter
Connection of the grounding conductor [}48].
ð The installation is completed. In the next step, connect the drive controller.
