11 | Appendix STOBER
88
03/2020 | ID 442793.03
11.1.8 ISPC 5 -STGCL-7,62
Feature Line type Value
Contact spacing — 7.62mm
Nominal current at ϑ
amb
= 40°C — CE/UL/CSA:
32A/35A/35A
Max. conductor cross-section Flexible without end sleeve 6.0mm²
Flexible with end sleeve without plastic collar 6.0mm²
Flexible with end sleeve with plastic collar 4.0mm²
2 conductors, flexible, with double end sleeve with
plastic collar
1.5mm²
AWG according to UL/CSA 8
Min. conductor cross-section Flexible without end sleeve 0.2mm²
Flexible with end sleeve without plastic collar 0.25mm²
Flexible with end sleeve with plastic collar 0.25mm²
2 conductors, flexible, with double end sleeve with
plastic collar
0.25mm²
AWG according to UL/CSA 24
Insulation stripping length — 15mm
Tightening torque — —
Tab. 95: ISPC 5 -STGCL-7,62 specification
11.1.9 ISPC 16 -ST-10,16
Feature Line type Value
Contact spacing — 10.16mm
Nominal current at ϑ
amb
= 40°C — CE/UL/CSA:
55A/66A/66A
Max. conductor cross-section Flexible without end sleeve 16.0mm²
Flexible with end sleeve without plastic collar 16.0mm²
Flexible with end sleeve with plastic collar 10.0mm²
2 conductors, flexible, with double end sleeve with
plastic collar
4.0mm²
AWG according to UL/CSA 4
Min. conductor cross-section Flexible without end sleeve 0.75mm²
Flexible with end sleeve without plastic collar 0.75mm²
Flexible with end sleeve with plastic collar 0.75mm²
2 conductors, flexible, with double end sleeve with
plastic collar
0.75mm²
AWG according to UL/CSA 20
Insulation stripping length — 18mm
Tightening torque — —
Tab. 96: SPC 16 -ST-10,16 specification
