STOBER 9 | Commissioning
03/2020 | ID 442793.03
77
9.3 Testing the project configuration
Before you continue parameterizing your application, we recommend testing your projected axis model using the jog
control panel.
Check your projected axis model as well as your configured electrical and mechanical data for plausibility by transferring
your project configuration to one of your drive controllers for test purposes and controlling the drive using the jog control
panel instead of using a controller.
1. Highlight the relevant drive controller in the project tree and click on the first projected axis in the project menu >
Wizard area.
2. Select Jog control panel.
3. The predefined test movement variables are default values. Check them and, if necessary, change the values such that
you can intervene in an emergency before personal injury or material damage can occur.
Information
Always check the reliability of the default values before starting the test. If they appear too large or unsuitable compared
with the results of the scaling calculator, always replace them with values that are more suitable for test operation.
Transmitting the configuration
ü
You have verified the plausibility of the predefined test movement variables. To transfer a configuration to a drive
controller, you must connect your PC and the drive controller to the network.
ü
The relevant drive controller is switched on.
1. In the project tree, highlight the module under which you have recorded the drive controller and click Assignment and
live firmware update in the project menu.
ð The Add connection window opens. All drive controllers found via IPv4 limited broadcast are displayed.
2. Direct connection tab > IP address column:
Activate the IP address in question or activate all listed using the context menu. Confirm your selection with OK.
ð The Assignment and live firmware update window opens. All drive controllers connected through the previously
selected IP addresses are displayed.
3. Select the drive controller to which you would like to transfer the configuration. Change the selection of transmission
type from Read to Send.
4. Change the selection Create new drive controller: Select the configuration that you would like to transfer to the drive
controller.
5. Repeat steps 3 and 4 for all other drive controllers to which you would like to transfer your configuration.
6. Online tab:
Click on Establish online connection.
ð The configurations are transferred to the drive controllers.
