9 | Commissioning STOBER
78
03/2020 | ID 442793.03
Information
During the search, all drive controllers within the broadcast domain are found via IPv4 limited broadcast.
Prerequisites for finding a drive controller in the network:
▪ Network supports IPv4 limited broadcast
▪ All drive controllers are in the same subnet (broadcast domain)
Saving the configuration
ü
You have successfully transferred the configuration.
1. Assignment and live firmware update window:
Click on Save values (A00) ....
ð The Save values (A00) window opens.
2. Click on Start action.
ð The configuration is saved.
3. Close the Save values (A00) window.
4. Assignment and live firmware update window:
Click on Restart (A09) ....
ð The Restart (A09) window opens.
5. Click on Start action.
6. Confirm the safety instruction with OK.
ð The Restart (A09) window closes.
ð The fieldbus communication and connection to DriveControlSuite are interrupted.
ð The drive controllers restart.
Activating the control panel and testing the project configuration
ü
The STO safety function must not be activated.
1. Select Jog control panel.
2. Click Control panel on and then Enable.
ð The drive is controlled using the activated control panel.
3. Move the axis step-by-step and test the direction of motion, velocity, distances, etc. using the Jog+, Jog−, Jog step+
and Jog step− buttons.
4. Optimize your project configuration based on your test results as necessary.
5. To deactivate the control panel, click on Control panel off.
Information
Jog+ and Jog− cause a continual manual movement in the positive or negative direction. If both buttons are active, no
movement is executed.
Jog step+ and Jog step– move the drive relative to the current actual value by the increment specified in I14.
Jog+ and Jog− have a higher priority than Jog step+ and Jog step−.
