Stober SC6A062 Commissioning Instructions

1 | Foreword STOBER
6
03/2020 | ID 442793.03
1 Foreword
The compact stand-alone SC6 drive controller allows for sensorless control of STOBER Lean motors of the LM series. These
motors provide energy efficiency at the performance level of synchronous servo motors. They also guarantee high
investment protection, thanks to energy efficiency class IE5 and the corresponding higher efficiency compared to IE4
asynchronous motors. However, the SC6 can also be used in combination with asynchronous motors or synchronous servo
motors with encoders (e.g. the EZ series). SC6 is available in three sizes with a nominal output current of up to 19A: sizes 0
and 1 as a double-axis controller, size 2 as a single-axis controller.
Features
§ Sensorless position control by STOBER Lean motors
§ Control of rotary synchronous servo motors, asynchronous motors and torque motors
§ HIPERFACE DSL One Cable Solution
§ Electronic motor nameplate via HIPERFACE DSL or EnDat 2.2 digital encoder interface
§ Integrated EtherCAT or PROFINET communication
§ STO safety technology using terminals or STO and SS1 using FSoE (Safety over EtherCAT): SIL3, PLe (cat.4)
§ Integrated brake control
§ Single-ended nominal power consumption on double-axis controllers for operation of motors with different power
§ Energy supply through direct power supply
§ Flexible DC link connection for multi-axis applications

Stober SC6A062 Specifications

General

Brand	Stober
Model	SC6A062
Category	Controller
Language	English
