99 B58FZS 0000000078 EN 002
SERVICING
The FZ front loader has 12 lubrication points on each side:
Fig. 92 Lubrication points on the FZ
The grease nipple at Position 1 can only be reached by slightly lifting the front loader and putting it down
on the tip of the implement.
8.1.2 Lubrication schedule
Shorten the lubrication intervals if there is strong dirt contamination.
Lubrication point Interval
(operating hours)
Lubricant
Bearing positions 20 h Multipurpose grease DIN 51502 K2K,
ISO 6743 ISO-L-XCCEA2, or comparable product
Front loader mountings (catch hooks) 100 h
Front loader locking mechanism 100 h Multipurpose grease or lubricating oil
