89 B58FZS 0000000078 EN 002
OPERATION
6.6 Levelling in reverse
NOTICE
Material damage due to improper levelling!
If the front loader is not correctly used for levelling, the machine can be overloaded and damaged.
Only perform levelling work with bucket implements.
Level only with the front edge of the bucket.
Maintain a maximum angle of 45° between the bottom edge of the bucket and the ground.
Only drive in reverse with the bucket in this position.
Do not exceed a speed of 10 km/h.
With a bucket implement, the front loader can perform light levelling work.
Levelling in reverse:
(1) Lower the front loader.
(2) Use the dumping and scooping function until
the angle between the bottom edge of the
bucket and the ground does not exceed 45°.
(3) Slowly drive in reverse.
The ground is levelled.
Fig. 89 Levelling in reverse
Legend
1 Maximum angle of 45° between the bottom edge of
the bucket and the ground
2 Maximum speed of 10 km/h
B049
11
2
2
