OPERATION
6.1.6 Switch/changeover switch
Rapid emptying and quick emptying/3rd control circuit
To prevent simultaneous use of rapid emptying
and quick emptying (see 4.6 Rapid traverse
emptying (FS) and quick emptying (FZ-L)) and
functions of the 3rd control circuit
(see 4.9.1 Additional control circuits), both
functions are assigned to the same switch.
RTL/4th control circuit
The switch must be used to pre-select the
functions
of the 4th control circuit (see 4.9.1 Additional
control circuits) and return-to-level
(see 4.7 Return-To-Level (FZ-L)).
This switch is only equipped if there is no
three-button operating lever.
Fig. 61 Switch for rapid or quick emptying and 3rd
control circuit
Legend
1 Switch position for rapid or quick emptying
2 Switch position for 3rd control circuit
3
RD
11
22
B07C
Fig. 62 Switch for the RTL function and 4th control
circuit
Legend
1 Switch position for RTL
2 Switch position for 4th control circuit
4
RTL
TH
11
22
B08J
