OPERATION
6.1.2 Tractor's own operating lever
⚠ WARNING
Risk of injury due to unexpected movement of the front loader!
The front loader can move unexpectedly as a result of unintentional actuation of the operating lever or
by programmed sequences. This can cause injury to persons in the surrounding area.
 Lock the operating lever in the zero setting when the front loader is not in use.
 If it is not possible to lock the operating lever, close the shut-off valve in the lifting hydraulic line.
 Immobilise the lock-in position of the hydraulic control units.
 Before using the front loader, immobilise or disconnect other implements on the tractor.
 Immobilise or disconnect the front loader before using other implements.
 Never use programmed sequences for the front loader.
⚠ WARNING
Risk of accident due to wrong assignment of the hose lines!
If the front loader is connected directly to the auxiliary control units of the tractor with hose lines,
swapping of the hose lines can result in incorrect assignment of the functions on the operating lever.
This can result in unexpected movements and accidents.
 Always mark the couplings on the hose lines and connection points.
 Promptly replace damaged or missing labels.
 Connect the hose lines so that the float position takes place in the actuation direction of the lowering
function.
 After connecting, check all of the functions of the front loader while at a standstill.
The operating lever can look different depending on the tractor model. However, the control of basic
functions remains the same (see 6.1.1 Basic controls with levers).
The assignment of the buttons is arranged as follows:
Operating lever with one button
Operating lever with 2 buttons
Button Front loader Function Additional function with
changeover switch
A FS, FZ 3rd control circuit -
FS-rapid
emptying
Rapid emptying 3rd control circuit 4.6 Rapid traverse
emptying (FS) and quick
emptying (FZ-L)
Button Front loader Function Additional function with
changeover switch
A FS, FZ 3rd control circuit -
FS-rapid
emptying
Rapid emptying 3rd control circuit 4.6 Rapid traverse
emptying (FS) and quick
emptying (FZ-L)
FZ-L Quick emptying 3rd control circuit
B FS, FZ 4th control circuit -
FZ-L Return-to-Level 4th control circuit 4.9.1 Additional control
circuits
