STRUCTURE
3.4 Attaching it to the tractor
The front loader is attached to the tractor using the mounting kit for tractors. The mounting kit consists
of the following components:
Fig. 9 Mounting kit for tractors
Legend
1 Front guard left and right
2 Mounting parts left and right
3 Mountings/catch hooks
The components remain permanently mounted on the tractor. They can look different depending on the
tractor model.
Observe the installation instructions for the mounting kit.
Observe the regulations for the registration of the changed empty weight in the vehicle documents
for the tractor.
The front loader can only be mounted on the tractor if the associated mounting kit is already
installed. Only an authorized specialist workshop is allowed to install the mounting kit on the
tractor.
