TECHNICAL SPECIFICATIONS
11 Technical specifications
11.1 Dimensions and weights
11.2 Noise emissions
The emission sound pressure level is less than 70 dB(A) (depending on the tractor).
Front loader Nominal width
1
[mm]
Lifting arm length
2
[mm]
Nominal lifting force
3
[daN]
Weight
4
[kg]
FS 8 916 2300 1660 356
FZ 8 2300 1660 406
FS 10 2500 1720 420
FZ 10 2500 1720 465
FS 20 2500 2120 425
FZ 20 2500 2120 475
FS 30 2720 1950 470
FZ 30 2720 1950 540
FS 40 2720 2240 480
FZ 45 2720 2260 580
FZ 50 2850 2430 680
FZ 60 3000 2630 790
FS 8.1 1100 2300 1660 366
FZ 8.1 2300 1660 416
FS 10.1 2500 1720 430
FZ 10.1 2500 1720 475
FS 20.1 2500 2120 435
FZ 20.1 2500 2120 485
FS 30.1 2720 1950 484
FZ 30.1 2720 1950 544
FS 40.1 2720 2240 494
FZ 45.1 2720 2260 594
FZ 50.1 2850 2430 694
FZ 60.1 3000 2630 805
FZ 80.1 3200 2740 850
FZ 100 1450 3500 3500 1250
1
Measured from the centre of the pillar to the centre of the pillar.
2
Measured from the lifting arm pivot point to the implement pivot point.
3
Mathematically determined lifting force in the implement pivot point with hydraulic pressure at 195 bar, lifting arm raised to
1.5 m and ideal typical mounting. Since the geometry of the actual mounting parts must also take the specific geometry of
different tractor equipment (tire sizes, axles, etc.) into account, the actual values in individual cases may vary significantly.
The lifting capacity at the highest position of the front loader is up to 15% lower, the lifting capacity on the ground is
correspondingly higher.
4
Typical weight without implement, without special equipment. Deviations in individual cases are possible.
