105 B58FZS 0000000078 EN 002
DECOMMISSIONING
9 Decommissioning
9.1 Temporary decommissioning
⚠ WARNING
Risk of injury due to lacking stability!
If the front loader is not correctly and safely parked, it can tip over and injure persons nearby.
Only park the front loader with a mounted implement that weighs at least 70 kg.
Use the parking supports and lock them correctly.
Only park the front loader on load-bearing and level ground.
Dismounting the front loader:
(1) Switch off the tractor.
Apply the parking brake.
Stop the engine.
(2) Lower the front loader to the ground.
(3) Release the front loader locking mechanism
on both sides (see 5.5 Mounting the front
loader).
(4) Unfold the parking supports
(see 6.2 Operating the parking supports).
(5) Start the tractor.
Fig. 97 Apply the parking brake and lower the front
loader
B07J
Fig. 98 Releasing the front loader locking mechanism
B08D
Fig. 99 Unfolding the parking supports
B07L
