STRUCTURE
3.5.2 SMS change frame
These change frames are installed on FS and
FZ 8 to 80.1 front loaders.
The implement is hinged on the top cross bar and
is secured with the locking mechanism.
Its function is similar to that of the Euro change
frame.
3.5.3 Euro-SMS Combi change frame
These change frames are installed on FS and
FZ 8 to 80.1 front loaders.
They are intended for mounting implements
complying with the Euro standard as well as the
SMS standard.
Euro implements are hinged onto the outer pins.
SMS implements are hinged onto the cross bar.
The function is the same as for Euro and
SMS change frames.
Fig. 11 SMS change frame
Legend
1 Upper cross bar
2 Locking mechanism
B06J
11
22
Fig. 12 Euro-SMS Combi change frame
Legend
1 Outer pin
2 Cross bar
11
2
2
B06K
