B58FZS 0000000078 EN 002 28
STRUCTURE
Legend
1 Pillars (drive-in system)
2 Lifting arm (base frame)
3 Lifting cylinder: hydraulic cylinder for lifting and lowering
4 Deviation triangle of the parallel motion
5 Indicator for implement position
6 Implement cylinder: hydraulic cylinder for dumping and scooping (synchronised cylinder)
7 Parking supports
8 Rating plate
9 Lever mechanism dumping/scooping
10 Euro change frame (implement support)
11 Implement locking mechanism
12 Cap for hydraulic and electrical distribution and additional equipment
13 Front loader locking mechanism
14 Coupling holder
15 Control rod of the parallel motion
16 Hydraulic couplings for the 3rd and 4th control circuit (optional)
17 Hydraulic and electrical distribution valves for additional equipment
18 Cross tube
19 Hydraulic tubes
20 Hydraulic hoses to the tractor (interface on the mounting part)
21 Connection cable (optional, multiple versions possible)
Sizes, see 11 Technical specifications.
