Stonex R20 – User Manual 22
Enter {level & Plummet} to switch on and set the plummet laser, set tilt
compensation mode, and perform leveling.
Switch on/off the buzzer. When switch on, the key tone and beep will be actived.
Switch on/off the illumination of the reticle.
Switch on/off the function of the trigger key.
4.8. Edit
Input
In some procedures, the operator is required to input numbers or characters.
Input numbers: In the input field, press [F4]【123】to switch to numeric input mode. Only numbers and the "-"
and "." symbols can be entered. A short press on a numeric key will input the corresponding number or character
in the active input box on the display.
Input characters: In the input field, press [F4]【ABC】to switch to character input mode. Capital letters, numbers
and common symbols can be entered. Click a numeric key to enter the letter, number or symbol corresponding to
the key. A quick repetitive press will switch and cycle between the numbers and the letters and symbols printed
above the keys. For example, the key [1], press once to input "S", press again to input "T", press again to input "U",
press again to input "1", press again to input "S", …
Edit
Existing strings in the input field can be edited.
Move the cursor to the left.
Move the cursor to the right.
Toggle the input mode between insert and modify. The cursor state is either a vertical
line between characters or a block covering a character, respectively.
Delete a character to the left of the cursor.
Clear all the characters of the current input field.
Switch the numeric input or character input mode.
Search
In the interface that supports search, the softkey [Search] will be available. Search is used in file management or
applications to find specific measured or fixed points in memory. The search function requires entering the exact
point name.
The search can be limited to a specific job or to all records. A fixed point that satisfies the search criteria is always
