STONEX R20 - Angle Measurement

Stonex R20 – User Manual 26
Distance Measurement:
Press the [ ] fixed function key in the measurement interface to enter the distance measurement mode.
Page
Key
Softkey
Function
1
[F1]
【Dist】
Trigger distance measurement.
[F2]
【HA=0】
Set the horizontal angle to 0°00′00″.
[F3]
【EDM】
Enter {EDM Setting}.
[F4]
【P1/2】
Turn to the 2
nd
page of softkeys.
2
[F1]
【Offset】
Enter {Offset}.
[F2]
【StOut】
Enter {Stake Out}.
[F3]
【m/ft】
Convert distance units between meters and inches.
[F4]
【P2/2】
Turn to the 1
st
page of softkeys.
Coordinates Measurement:
Press the [ ] fixed function key in the measurement interface to enter the coordinates measurement mode.
Page
Key
Softkey
Function
1
[F1]
【Dist】
Trigger distance measurement.
[F2]
【HA=0】
Set the horizontal angle to 0°00′00″.
[F3]
【EDM】
Enter {EDM Setting}.
[F4]
【P1/3】
Turn to the 2
nd
page of softkeys.
2
[F1]
【hr】
Input the prism height.
[F2]
【hi】
Input the instrument height.
[F3]
【STN】
Enter {Set Station}
[F4]
【P2/3】
Turn to the 3
rd
page of softkeys.
3
[F1]
【Offset】
Enter {Offset}.
[F2]
【BS】
Enter {Back Sight}.
[F3]
【m/ft】
Convert distance units between meters and inches.
[F4]
【P3/3】
Turn to the 1
st
page of softkeys.
5.2. Angle Measurement
Measure the HA and VA
