Stonex R20 – User Manual 72
In the last calculated value interface, Press [ESC] can quit the calibraton and retain the old parameters.
During the calibration process, the program may pop up a message warning if the operation does not comply with
the specifications.
〈VA not suitable for calibration〉
The VA was too far off 90°, or aiming deviation was too big in face II.
〈HA not suitable for calibration〉
Aiming deviation was too big in face II.
〈Out of tolerance！Retained〉
The calculation result is exceeded tolerance due to improper
operation; the instrument will retain the original set value.
12.4. Mechanical Check and Adjust
Check and Adjust the Instrument Plate Level and Tribrach Circular Level
