STONEX R20 - 13 Technical Data; Angle Measurement; Distance Measurement

Stonex R20 – User Manual 74
13. Technical Data
13.1. Angle measurement
Accuracy
2”
Standard deviation
0.6 mgon
1
Reading system
Absolute encoder, continuous
Display resolution (selectable)
Unit
Options
° ’ “
1〞/5〞/10〞
°
0.0001/0.0005/0.001
gon
0.0001g/0.0005g/0.001g
mil
0.01mil/0.05mil/0.1mil
13.2. Distance measurement
Characteristics
Principle:
Type:
Wavelenght:
Laser class:
Phase measurement
Red light, coaxial
685nm @25°C
3R (NonPrism) / 1 (Prism & Refl. Tape)
Display resolution (selectable)
Unit
Options
m
0.001m/0.0001m
US-ft
0.001ft/0.0001ft
INT-ft
0.001fi/0.0001fi
ft-in
1
16
⁄
00.00.01
Range
Prism
2
: 3.500m
EDM mode
Accuracy
3
Measurement time [sec]
Standard
2mm+2ppm
0.8
Fast
5mm+2ppm
0.5
Track
5mm+2ppm
0.3
NonPrism
2
:
600m
Distance [m]
Accuracy
3
Measurement time [sec]
@5-200m
3mm+2ppm
≥0.3
@>200m
5mm+2ppm
≥0.3
Refl. Tape
2
:
800 m
Shortest measuring distance: 0.2 m
