page 6–67
1069–42–50 Optional Dual Articulating Crank Fowler Assembly
Item Part No. Part Name Qty.
A 1069–32–55 Fowler Skin 1
B25–50 Pop Rivet 9
C7–42 Truss Hd. Screw 4
D 1069–32–50 Fowler Weldment 1
E 1069–31–12 Barrel Nut 4
F (page 6–70) Head Piece Assembly 1
G 1069–33–93 Head Pivot Shaft 1
H52–17 Nylon Flat Washer 2
J4–74 Button Hd. Screw 2
K4–54 Button Hd. Screw 2
L16–11 Nylock Nut 2
M 7900–1–102 Velcro Pile 2
N 1069–31–13 Hole Plug 2
P11–179 Washer 4
