page 6–77
1068–46–10 Optional Knee Gatch Crankscrew Assembly
Item Part No. Part Name Qty.
A 946–33–18 Crank Disk 1
B 1550–1–16 Crank Handle 1
C26–45 Roll Pin 1
D26–14 Roll Pin 2
E81–176 Thrust Washer 1
F81–175 Thrust Bearing 1
H81–174 Thrust Washer 2
J 938–1–175 Bearing Assembly 1
K 938–1–177 Knob 1
L 378–24–29 Shoulder Bolt 1
M16–5 Conelock Nut 1
N 946–34–25 Knee Gatch Screw 1
P 1510–34–84 Screw Cover Assembly 1
R 1068–46–12 Gatch Drive Tube Assembly 1
S26–10 Roll Pin 2
T 7900–1–102 Velcro Pile Tape .3’
W4–7 Soc. Head Cap Screw 1
Y 1550–1–14 Magnet 1
