Stryker 1069 - Pivot Rod Assembly

page 6–24
1010–260 Optional Fifth Wheel Assembly
U
FOOT END
HEAD END
Item Part No. Part Name Qty.
A14–79 Nylon Washer 1
B11–13 Washer 1
C27–16 Cotter Pin 1
G (page 6–25) Pivot Rod Assembly 1
H 1210–1–145 Cam 1
J 1210–1–148 Torsion Spring 1
M 1210–201–149 Spring Spacer 1
O4–10 Bolt 1
P (page 6–26) Wheel Arm Assembly 1
R 1210–1–146 Torsion Spring 1
S26–35 Roll Pin 1
T (page 6–23) Caster Assembly 4
U 715–1–158 Caster Nut 4
X14–80 Nylon Washer 2
