page 6–82
Optional Transfer System Assembly
HEAD END
Assembly part number
1060–58–10
(reference only)
Item Part No. Part Name Qty.
A2–100 Pan Hd. Mach. Screw 4
B3–73 Hex Hd. Cap Screw 8
D11–2 Washer 4
E11–180 Washer 8
H16–3 Fiberlock Nut 4
J16–28 Nylock Nut 8
K38–218 Extension Spring 2
L 1010–24–25 Spring Retainer 2
M (page 6–85) Board Support Assembly 2
N (page 6–83) Arm Board Ass’y, Left 1
P (page 6–84) Arm Board Ass’y, Right 1
To Next Page
