page 6–74
Stationary Foot Section Assembly
Assembly part number 1068–44–10
(reference only)
Item Part No. Part Name Qty.
A3–73 Hex Hd. Cap Screw 2
B14–3 Washer 2
C16–28 Nylock Hex Nut 4
D25–101 Rivet 26
E 1010–32–60 Pivot Bolt 2
H 1068–44–44 Stationary Foot Skin 1
J 1068–44–50 Stationary Foot Weldment 1
K 381–24–7 Velcro Adhesive Pile 1
