page 4–2
Siderail Latch Adjustment
Required Tools:
1/8” Hex Allen Wrench
WARNING
The siderail latch adjustment is pre–set at the factory, and there should not normally be a need for readjust-
ment. If adjustment must be done it is important to follow the procedure below. If it is not done properly, injury
to the patient or user could occur.
Adjustment Procedure:
1. Using a 1/8” hex Allen wrench, adjust the hex Allen screw located on the latch assembly opposite the
latch. Turning the screw clockwise will DECREASE the amount of play in the latching mechanism. Turn-
ing counterclockwise will INCREASE the amount.
NOTE
The amount of play in the siderail, when in full up engaged position, should be approximately 1/8 to 3/16 in-
ches.
CAUTION
Too much play when the siderail is in the full up engaged position will give the siderail the appearance of being
unstable and could also cause premature wearing of the latch system.
Too little play will obstruct the latch and keep it from engaging completely in the full up position, which may
cause damage to the latch and/or injury to the patient or user.
Arm Board Counterbalance Adjustment
Required Tools:
7/16 Open End Wrench
Adjustment Procedure:
1. Raise the arm board to the full up position.
2. Unhook the extension spring at the eye bolt.
3. Using a 7/16 open end wrench, loosen the jam nut at the eye bolt.
4. Adjust the eye bolt to the desired position.
5. Tighten the jam nut.
6. Hook the extension spring to the eye bolt.
7. Allow the arm board to lower on its own.
8. Repeat steps 1–7 until the desired counterbalance is achieved.
