Stryker 1069 - Page 128

page 6–89
Optional Pre–Op/Post Op Head Piece Assembly, Crank Fowler
Right Head Piece
Left Head Piece
Item Part No. Part Name Qty.
A38–162 Pin Slide Spring 1
B 1069–60–40 Tube Weldment, Right 1
1069–60–50 Tube Weldment, Left 1
C 1069–60–90 Head Extension Label 1
D 1069–60–140 Slider Pin 1
E 1069–60–142 Spring Spacer 1
F 1069–60–145 Cam Pin 1
G 1069–60–12 Latch Knob 1
H 1069–260–91 Latch Release Label 1
J 7900–1–102 Velcro Pile (4.5”)2
K26–179 Spirol Pin 3
L8–20 Shoulder Bolt 1
