page 6–6
Side Control Base Assembly
Item Part No. Part Name Qty. Item Part No. Part Name Qty.
A 715–1–11 Brake Cushion 4 AW 3–62 Hex Hd. Cap Screw 8
B 715–1–61 Caster Brake Weldment 2 AX 3–85 Hex Hd. Cap Screw 8
C 715–1–92 Pump Pedal Shaft 1 AY 4–146 Soc. Hd. Cap Screw 2
D 715–201–94 Compression Spring 2 BA 8–17 Shoulder Bolt 2
E 715–1–133 Collar 1 BB 11–3 Washer 12
F 715–1–140 Vinyl Tube 1 BC 11–262 Washer 12
G (page 6–11) Brake Adjuster 2 BD 13–38 Ext. Tooth Lock Washer 4
H 715–1–156 Ground Chain 1 BE 14–2 Washer 6
K 715–1–158 Caster Nut 4 BF 14–9 Washer 2
L 715–1–165 Actuator Plate Weldment 2 BG 16–2 Hex Nut 2
M 715–1–192 Jack Support 2 BK 16–28 Hex Nut 4
N 715–1–193 Jack Support Clamp 2 BL 16–36 Hex Nut 16
P 715–1–214 Connecting Link 1 BM 16–48 Hex Nut 2
R 715–1–333 Release Rod Stop Sleeve 2 BN 21–22 Set Screw 2
S 715–1–346 Release Paddle 2 BP 21–50 Set Screw 2
X 715–201–27 Pump Rod Assembly 1 BR 23–25 Self–Tapping Screw 1
Y (page 6–13) Pump Pedal Assembly 1 BS 26–13 Spring Pin 2
Z 715–201–126 Slip–On Pump Pedal 2 BW 27–4 Cotter Pin 2
AA (page 6–12) Brake Cam Assembly 2 BX 29–7 Velcro Loop 6
AB 37–237 Round Vinyl Cap 1 BY 29–9 Velcro Pile 6
AC 38–246 Jack Spring 1 BZ 38–355 Extension Spring 2
AD 763–1–16 Spring Holder 1 CA 42–20 Collar 2
AE 946–1–116 Brake Bar Bushing 4 CB 52–245 Nyliner 2
AF 1068–201–45 Brake/Steer Rod Ass’y 1 CC 52–747 Flange Bearing 4
AG 1210–1–114 Pedal Pivot, Left 1 CD 52–284 Spacer Washer 1
AH 1210–1–115 Pedal Pivot, Right 1 CE 27–3 Cotter Pin 2
AK 1210–201–120 Base Frame Weldment 1 CF 11–4 Washer 2
AL 1210–201–139 Pull Release Rod, Head 1 CG (page 6–16) Jack Assembly 2
AM 1210–201–152 Release Pedal Weldment 2 (page 6–18) Constant Flow Jack Ass’y2
AN 1210–201–153 Butterfly “V” Pedal 1 CH 26–143 Groove Pin 3
AP 1210–201–222 Push Release Rod 1 CJ (page 6–23) Caster Assembly *
AR 1210–201–251 Insert 3 CK 715–1–265 Wheel Cover, Right 4
AT 3–47 Hex Hd. Cap Screw 4 CL 715–1–266 Wheel Cover, Left 4
* Caster assembly is quantity of 4 if the fifth wheel option is present on the stretcher and quantity of 3 if the steering caster
option is present.
