End Control Base Assembly
Item Part No. Part Name Qty. Item Part No. Part Name Qty.
A 715–1–11 Brake Cushion 4 BB 3–4 Hex Hd. Cap Screw 4
B 715–1–61 Caster Brake Weldment 2 BC 3–62 Hex Hd. Cap Screw 8
D 715–201–94 Compression Spring 2 BD 3–85 Hex Hd. Cap Screw 8
E 715–1–133 Collar 2 BE 8–17 Shoulder Bolt 2
F 715–1–140 Vinyl Tube 2 BF 11–3 Washer 4
G (page 6–11) Brake Adjuster 2 BG 11–13 Washer 2
H 715–1–156 Ground Chain 1 BH 11–262 Washer 10
K 715–1–158 Caster Nut 4 BK 11–350 Spacer Washer 1
L 715–1–165 Actuator Plate Weldment 2 BL 13–38 Ext. Tooth Lock Washer 4
M 715–1–192 Jack Support 2 BM 14–2 Washer 7
N 715–1–193 Jack Support Clamp 2 BP 14–3 Washer 2
S 715–1–333 Release Rod Stop Sleeve 2 BR 14–7 Washer 4
T 716–1–109 Pump Link, Head End 1 BS 14–9 Washer 2
W 715–201–126 Slip–On Pump Pedal 2 BT 15–11 Hex Nut 4
X (page 6–12) Brake Cam Assembly 2 BU 16–2 Hex Nut 2
Y 716–1–15 Release Pivot Bar 2 BW 16–14 Nylock Nut 2
Z 716–1–102 Pump Link, Foot End 1 BX 16–102 Hex Nut 4
AA 716–1–119 Pivot Ass’y, Head End 1 BY 16–36 Hex Nut 16
AB 716–1–286 Release Ball Spacer 4 BZ 21–151 Set Screw 2
AC 716–1–52 Pivot Ass’y, Foot End 1 CA 23–25 Self–Tapping Screw 1
AD 716–201–61 Rel. Pedal Pivot Rod 2 CB 26–13 Spring Pin 2
AE 716–201–70 Long Release Rod 2 CC 26–195 Clevis Pin 2
AF 716–201–74 Release Rod 2 CD 715–1–265 Wheel Cover, Right 4
AG 716–201–281 Pump Idler Link 2 CE 27–4 Cotter Pin 9
AH (page 6–14) Pump Pedal Ass’y, Ft. End 1 CF 27–3 Cotter Pin 9
AK (page 6–15) Pump Pedal Ass’y, Hd. End 1 CG 27–16 Cotter Pin 2
AL 763–1–15 Jack Spring 1 CH 28–97 External Retaining Ring 2
AM 763–1–16 Spring Holder 1 CK 29–7 Dual Lock 6
AN 946–1–116 Brake Bar Bushing 4 CL 29–9 Dual Lock 6
AO 715–201–230 Brake/Steer Rod Ass’y 1 CM 38–235 Descent Pedal Ret. Spring 4
AP 1210–1–112 Rel. Rod, Head End, Left 1 CN 38–251 Pump Return Spring 2
AR 1210–201–27 Pump Rod Angle 1 CP 38–326 Extension Spring 2
AS 1210–201–111 End Rel. Pedal Bracket 2 CR 42–20 Collar 2
AT 1210–201–120 Base Frame Weldment 1 CS 52–245 Nyliner 4
AU 1210–201–551 Eye Bolt 2 CT (page 6–16) Jack Assembly 2
AW 1210–201–153 Butterfly “V” Pedal 2 (page 6–18) Constant Flow Jack Ass’y2
AX 1210–201–154 Rel. Pedal, Offset, Hd., Rt. 2 CV (page 6–23) Caster Assembly *
AY 1210–201–155 Rel. Pedal, Offset, Ft., Lt. 2 CW 26–143 Groove Pin 4
AZ 1210–201–201 Pivot Pin Bracket, Foot 1 CX 1210–201–200 Pivot Pin Bracket, Head 1
BA 1210–201–251 Insert 3 CY 715–1–266 Wheel Cover, Left 4
* Caster assembly is quantity of 4 if the fifth wheel option is present on the stretcher and quantity of 3 if the steering caster
option is present.
