page 6–32
Side Control Base Labeling Assembly
Item Part No. Part Name Qty.
AA 1001–200–2 Base Hood 1
BB 715–1–134 Bellows 2
CC 1210–201–335 Red Brake Label 2
DD 1210–201–336 Green Steer Label 2
EE 946–201–60 Stryker Logo Label 2
Color
Set P/N
Item A Control
Label, Head End
Item B Control
Label, Foot End
Item C Control
Label, Right
Item D Control
Label, Left
Litter Bumper
Strip
RED
1068–702–210
1001–700–113 1001–700–114 1068–702–211 1068–702–212 1010–700–15
PURPLE
1068–702–220
1001–700–123 1001–700–124 1068–702–221 1068–702–222 1010–700–25
GREEN
1068–702–230
1001–700–133 1001–700–134 1068–702–231 1068–702–232 1010–700–35
GRAY
1068–702–240
1001–700–143 1001–700–144 1068–702–241 1068–702–242 1010–700–45
TEAL
1068–702–250
1001–700–153 1001–700–154 1068–702–251 1068–702–252 1010–700–55
PINK
1068–702–260
1001–700–163 1001–700–164 1068–702–261 1068–702–262 1010–700–65
BLUE
1068–702–270
1001–700–173 1001–700–174 1068–702–271 1068–702–272 1010–700–75
