Stryker 1069 - Page 76

page 6–37
Litter Assembly
Item Part No. Part Name Qty.
A 721–31–65 Hole Plug 24
B 721–32–49 Bumper Roller 2
C 721–32–107 Roller Sleeve 4
D 721–32–108 Support Roller 4
E 721–40–26 Foot Board Receptacle 2
F 1001–30–29 End Plug 2
G 1010–1–13 Foot Cover, Right 1
H 1010–1–14 Foot Cover, Left 1
J 1010–1–17 Roller Plate 2
K 1010–32–66 Rectangular Hole Plug 2
L (page 6–38) Foot End Jack Support Ass’y1
M 1068–20–38 Bumper Channel 2
N (page 6–39) Head End Jack Support Ass’y1
P 1069–30–50 Litter Frame Weldment 1
Q11–14 Washer 8
R16–28 Hex Nut 12
S25–38 Blind Rivet 16
T26–57 Spring Pin 4
U28–23 External Retaining Ring 2
V3–47 Hex Cap Screw 10
W3–54 Hex Cap Screw 2
X3–76 Hex Cap Screw 4
Y37–49 Rectangular Hole Plug 2
Z37–52 Rubber Bumper 2
AA 37–59 Hole Plug 1
AB 37–74 Hole Plug 4
AC 8–24 Soc. Hd. Shoulder Screw 2
