www.stryker.com 2030-809-002 REV D 101
EPIC II
®
PLUS Optional Base Assembly - 2030-201-210 (Reference Only)
Item Part No. Part Name Qty.
A 0003-032-000 Hex Hd. Cap Screw 4
B 0004-301-000 Pan Hd. Machine Screw 1
C 0005-017-000 Carriage Bolt 1
D 0007-052-000 Truss Hd. Torx 13
E 0011-063-000 Washer 5
F 0013-010-000 External Tooth Star Washer 5
G 0016-028-000 Nylock Nut 1
H 0016-036-000 Nylock Nut 1
J 0023-025-000 Hex Washer Hd. Screw 10
K 0023-281-000 Self-Tapping Screw 4
L 0025-079-000 Pop Rivet 1
M 0030-038-000 Split Bushing 1
N 0037-221-000 Hole Plug 1
P 0058-090-000 Threaded Stud 1
R 0059-133-000 Push-Mount Wire Clip 1
S 0059-192-000 Split Ferrite 1
T 2030-001-030 Base Power Assembly 1
U 2030-080-802 DC Jumper Assembly 1
W 2030-201-005 Hood Shroud 1
X 3001-200-022 Foot End Bottom Cover Assembly 1
Y 2040-001-017 Head End Bottom Cover Assembly 1
Z 2040-001-100 Drive Wheel Position Label 1
AA 2040-001-101 Charger Box Cover Label 1
AB 2040-001-102 Power Board Cover Label 1
AC 2040-301-809 Umbilical Cable Assembly 1
AD 3000-200-601 Brake Label 2
AE 3000-200-602 Stryker Logo Label 1
AF 3000-300-428 Gatch Link Sleeve 4
AG 3000-300-113 Wire Tie 2
AH 3002-001-100 Transformer 1
AJ 3002-001-015 Battery Tray Assembly 1
AK 3002-001-050 Charger Box Weldment 1
AL 3002-001-068 Power Board Cover 1
AM 3002-001-071 Charger/Inverter Cover 1
AN 3002-001-078 Hood Slot Trim 1
AP 3002-001-079 Hood Slot Trim Bracket 1
AR 3002-001-802 Inverter/Battery Cable 1
AS 7000-001-326 10” Foam Tape 2
EPIC II
®
PLUS, Optional Base Assembly
