www.stryker.com 2030-809-002 REV D 173
Left Common Components - 2032-402-305 Right Common Components - 2032-402-405
Item Part No Part Name Qty. Item Part No Part Name Qty.
A 0001-072-000 Ph. Flat Hd. Mach. Screw 4 A 0001-072-000 Ph. Flat Hd. Mach. Screw 4
B 0003-344-000 Hex Hd. Cap Screw 2 B 0003-344-000 Hex Hd. Cap Screw 2
C 0011-185-000 Washer 1 C 0011-185-000 Washer 1
D 0011-343-000 Shim Washer 3 D 0011-343-000 Shim Washer 3
E 0014-093-000 Washer 2 E 0014-093-000 Washer 2
F 0023-090-000 Pan Hd. Tapping Screw 4 F 0023-090-000 Pan Hd. Tapping Screw 4
G 0028-128-000 Retaining Ring 6 G 0028-128-000 Retaining Ring 6
H 3000-200-334 Extension Spring 1 H 3000-200-334 Extension Spring 1
J 3000-400-513 Wear Bushing 2 J 3000-400-513 Wear Bushing 2
K 3000-400-523 Panel Spacer 2 K 3000-400-523 Panel Spacer 2
L 3000-400-557 Sleeve Bearing 4 L 3000-400-557 Sleeve Bearing 4
M 3001-400-527 Outer Rail 1 M 3001-400-527 Outer Rail 1
N 3001-400-555 Mounting Bracket 1 N 3001-400-555 Mounting Bracket 1
P 3001-400-564 Glide Rod 2 P 3001-400-564 Glide Rod 2
R 3001-400-619 Outer Arm Cover 2 R 3001-400-619 Outer Arm Cover 2
T 3002-400-055 Release Lever Ass’y, Lt. 1 T 3002-400-065 Release Lever Ass’y, Rt. 1
U 3002-400-090 Ball Detent Clip Ass’y 1 U 3002-400-090 Ball Detent Clip Ass’y 1
V 3002-400-501 Latch 1 V 3002-400-501 Latch 1
W 3002-400-505 Bypass Pin 1 W 3002-400-505 Bypass Pin 1
Y 3002-400-509 Bypass Bushing Spacer 1 Y 3002-400-509 Bypass Bushing Spacer 1
AA 3002-400-511 Glide Rod Bumper Pad 2 AA 3002-400-511 Glide Rod Bumper Pad 2
AB 3002-400-512 Bumper Washer 2 AB 3002-400-512 Bumper Washer 2
AC 3002-400-513 Pivot Bushing 6 AC 3002-400-513 Pivot Bushing 6
AD 3002-400-519 Latch Bushing 1 AD 3002-400-519 Latch Bushing 1
AE 3002-400-528 Siderail Carrier 1 AE 3002-400-528 Siderail Carrier 1
AF 3003-400-526 Inner Panel 1 AF 3003-400-526 Inner Panel 1
AG 2032-401-030 FE Timing Link Ass’y, LH 1 AG 2032-401-025 FE Timing Link Ass’y, RH 1
AH 3003-400-520 Foot Rail 1 AH 3003-400-520 Foot Rail 1
AJ 5000-020-005 Inner Arm Cover 2 AJ 5000-020-005 Inner Arm Cover 2
AK 0003-226-000 Hex Washer Head Screw 4 AK 0003-226-000 Hex Washer Head Screw 4
AL 3001-400-558 Spacer 4 AL 3001-400-558 Spacer 4
AM 3003-400-580 Weldment, FE Support Plate 1 AM 3003-400-580 Weldment, FE Support Plate 1
Foot End Siderail Assembly
