Item Part No. Part Name Qty.
A 3000-200-201 Upper Lift Housing 1
B 3000-200-202 Lower Lift Housing 1
C 3000-200-251 Outer Screw 2
D 3000-200-204 Upper Housing Sleeve 2
E 3000-200-205 Upper Stage Nut 2
F 3000-200-249 Inner Screw, Standard Height 2
2040-200-249 Inner Screw, Enhanced Height 2
G 3000-200-207 Lower Stage Nut 2
H 3000-200-208 Glide Bushing 4
J 3000-200-209 Motor Pinion Gear 1
K 3000-200-210 Idler Gear 2
L 3000-200-252 Output Gear 2
M 3001-200-214 Motor Isolation Plate Assembly 1
N 3003-016-603 Lift Motor 1
3221-200-213 230V Lift Motor 1
P 3000-200-218 Idler Shaft, Lift 1
Q 3002-200-235 Idler Man. Over. Shaft 1
R 3000-200-220 Input Pinion Shaft 1
S 3000-200-223 Output Gear Thr. Washer 4
T 3000-200-224 Input Gear Thr. Washer 2
U 0081-212-000 Thrust Needle Roller Bearing 1
V 3000-200-226 Pinion Shaft Bushing 6
W 3001-200-228 Mounting Standoff 4
Z 3001-300-019 Isolation Sleeve 4
AA 3000-200-233 Lift Motor Coupler 1
AB 3000-200-234 Coupler Receiver 1
AC 3000-200-241 Crush Washer 2
AD 3000-300-455 Isolation Bushing 4
AE 3000-200-245 Gear Washer 5
AF 3000-200-246 Nylon Washer 1
AG 0011-408-000 Flat Washer 4
AH 0003-082-000 Hex Head Cap Screw 4
AJ 0004-213-000 Socket Head Cap Screw 4
AK 0058-044-000 Woodruff Key 3
AM 0003-331-000 Hex Washer Head Screw 4
AP 0028-121-000 Retaining Ring 2
AQ 0028-097-000 Retaining Ring 1
AS 0011-308-000 Serrated Belleville Washer 4
AX 3000-200-239 Potentiometer Drive Gear Shaft 1
AY 3000-200-216 Potentiometer Drive Gear 1
AZ 0051-022-000 Grease (ounces) 4
BA 0026-231-000 Dowel Pin 2
Lift Assembly
Lift Assembly (Standard Height) - 3000-200-275 (Reference Only)
Lift Assembly (Enhanced Fluoro Height Option) - 2040-243-275 (Reference Only)
