GENERAL DESCRIPTION
FUEL
INJECTION
(FUEL SYSTEMS)
C: CAUTION
Wear working clothing, including a cap, protec-
tive goggles, and protective shoes during opera-
tion.
. Remove contamination including dirt and corro-
sion before removal, installation or disassembly.
. Keep the disassembled parts in order and pro-
tect them from dust or dirt.
Before removal, installation or disassembly, be
sure to clarify the failure. Avoid unnecessary re-
moval, installation, disassembly, and replacement.
D:
PREPARATION TOOL
Be careful not to burn your hands, because each
part
On
the
vehicle
is
hot
after
running.
Be sure to tighten fasteners including bolts and
nuts to the specified torque.
Place shop jacks or Safety stands at the specified
points.
Before disconnecting electrical COntleCtOrS
Of
sensors or units, be sure to disconnect negative
terminal
from
battery.
Place “NO
FIRE”
signs near the working area.
Be careful not to Spill fuel on the floor-
ILLUSTRATION
B2M3876
TOOL NUMBER
24082AA150
(Newly adopted
tool)
22771 AA030
DESCRIPTION
CARTRIDGE
SELECT MONI-
TOR KIT
REMARKS
Troubleshooting for electrical system.
Troubleshooting for electrical systems.
English: 22771AA030 (Without printer)
German: 22771AA070 (Without printer)
French: 22771AA080 (Without printer)
Spanish: 22771
AA090
(Without printer)
