SUBARU SELECT MONITOR
Engine load data
Engine coolant temperature signal
Short term fuel trim bv front oxvaen (NF) sensor
ENGINE (DIAGNOSTICS)
6.
READ FREEZE FRAME DATA FOR ENGINE. (OBD MODE)
1)
On the ((Main Menu,, display screen, select the {Each System Check} and press the [YES] key.
2)
On the ((System Selection Menu>> display screen, select the {Engine Control System} and press the [YES]
key.
3)
Press the [YES] key after displayed the information of engine type.
4)
On the ((Engine Diagnosis,, display screen, select the
{OBD
System} and press the [YES] key.
5)
On the
<<OBD
Menu>) display screen, select the {Freeze Frame Data} and press the [YES] key.
A list of the support data is shown in the following table.
Calculated load valve
%
Coolant Temp. "C or OF
Short term fuel trim B1
%
Engine speed signal
Vehicle speed signal
I
Diagnostic trouble code (DTC) for freeze frame data
I
Freeze frame data
I
DTC
I
Engine Speed rPm
Vehicle Speed km/h or MPH
I
Air fuel ratio control system for bank 1
I
Fuel system for Bank1
I
ON
or OFF
I
I
~~
I
Lonq term fuel trim bv front oxvqen (NF) sensor
I
Lona term fuel trim
81
I
~~
%
1
Intake manifold absolute pressure signal
I
mmHg or kPa or inHg or
mi
1
Mani. Absolute Pressure
I
EN(D0HC TURBO)-42
To Next Page
