3-14 Sun Fire X4100/X4100 M2 and X4200/X4200 M2 Servers Service Manual • August 2009
■ If CPU model is 23xx, then the CPU count is 4 (for single-CPU server).
The single-CPU server configuration can be converted to a dual-CPU configuration
by adding a CPU that is identical to the one in CPU postion 0 and installing it into
CPU position 1.
For DIMM population rules for a single-CPU system, see Section 3.12.14.2, “Installing
DIMMs Into a Single-CPU System” on page 3-64.
3.12 Replaceable Component Procedures
Note – Customer-replaceable units (CRUs) may be replaced by the customer.
Field-replaceable units (FRUs) should be replaced only by trained service technicians.
Contact your Sun Service representative for assistance with FRU replacements. The
designations, CRU and FRU, are provided below.
Note – All graphics in this section show Sun Fire X4200 servers unless otherwise
noted. Both Sun Fire X4100 and X4200 servers are shown where significant
differences exist.
Caution – Before handling components, attach an ESD wrist strap to the grounding
post that is built into the rear of the chassis (see
FIGURE 1-6 for the location). The
system’s printed circuit boards and hard disk drives contain components that are
extremely sensitive to static electricity.
This section contains procedures for replacing the following components:
■ Section 3.12.1, “Replacing the Battery” on page 3-15 (CRU)
■ Section 3.12.2, “Replacing a CPU and Heatsink (Sun Fire X4100 and X4200
Servers)” on page 3-17 (FRU)
■ Section 3.12.3, “Replacing a CPU and Heatsink (Sun Fire X4100 M2/X4200 M2
Servers)” on page 3-23 (FRU)
■ Section 3.11, “HT Jumper Configuration for Single-CPU Servers (Sun Fire X4100
M2 and X4200 M2)” on page 3-13
■ Section 3.12.4, “Replacing the DVD-ROM Drive” on page 3-30 (FRU)
■ Section 3.12.5, “Installing a DVD-ROM Drive Upgrade Kit” on page 3-33 (FRU)
■ Section 3.12.6, “Replacing a Fan Module” on page 3-38 (CRU)
■ Section 3.12.7, “Replacing a Fan Connector Board” on page 3-41 (CRU)
