3-38 Sun Fire X4100/X4100 M2 and X4200/X4200 M2 Servers Service Manual • August 2009
11. Replace the chassis front bezel.
a. Align the pegs on the rear of the bezel with the corresponding holes in the
front of the chassis.
Note – Ensure that the new DVD-slot faceplate is over the DVD-ROM drive and that
the button on the DVD-slot faceplate is oriented toward the chassis bottom. See
FIGURE 3-2 on page 5.
b. Press the bezel evenly against the front of the chassis until it is flat against
the front of the chassis.
c. Open the fan bay door on the front cover and tighten the captive retaining
screw using an adjustable torque driver. Tighten the screw to 7 in-lbs
(0.8 Nm). See
FIGURE 3-7 on page 11.
12. Replace the main cover to the chassis:
a. Set the cover in place so that it aligns with the keyed openings in the chassis
sides.
b. Slide the cover toward the chassis front until it is firmly and squarely against
the edge of the front cover.
13. Return power to the server. See
Section 2.1 on page 2-2.
3.12.6 Replacing a Fan Module
Note – This component is a hot-swappable CRU and can be replaced by anyone.
Supported components and their part numbers are subject to change over time. For
the most up-to-date list of replaceable components for these servers, refer to:
http://sunsolve.sun.com/handbook_pub/Systems
1. Click the name and model of your server.
2. On the product page that opens for the server, click Full Components List to
view a list of components.
Use the following procedure to replace a fan module.
