3-44 Sun Fire X4100/X4100 M2 and X4200/X4200 M2 Servers Service Manual • August 2009
3.12.8 Replacing the Front Panel Indicator Board
Note – This component is a CRU and can be replaced by anyone.
Supported components and their part numbers are subject to change over time. For
the most up-to-date list of replaceable components for these servers, refer to:
http://sunsolve.sun.com/handbook_pub/Systems
1. Click the name and model of your server.
2. On the product page that opens for the server, click Full Components List to
view a list of components.
Use the following procedure to remove and replace the front panel indicator board.
1. Power off the server as described in
Section 3.4 on page 3-4.
2. If the server is in a rack, slide it far enough from the rack so that you can
remove the main cover and front cover. If you cannot safely view and access the
component, remove the server from the rack.
3. Remove the main cover as described in
Section 3.5 on page 3-6 or Section 3.8 on
page 3-10.
4. Remove the front bezel as described in
Section 3.6 on page 3-7 or Section 3.9 on
page 3-11.
Note – Always unfasten the bezel’s securing screw before removing the bezel.
5. Remove the front cover as described in
Section 3.7 on page 3-8 or Section 3.10 on
page 3-12.
