C-1
APPENDIX
C
Status Indicator LEDs
Note – The information in this appendix applies to all Sun Fire X4100/X4100 M2 and
X4200/X4200 M2 servers, unless otherwise noted in the text.
C.1 External Status Indicator LEDs
FIGURE C-1 and FIGURE C-2 show the locations of the external status indicator LEDs. A
Sun Fire X4200/X4200 M2 server is pictured, but the LED locations are the same for
the Sun Fire X4100/X4100 M2 server.
Refer to
TABLE C-3 and TABLE C-4 for descriptions of the LED behavior, which differs
slightly for Sun Fire X4100/X4100 M2 and X4200/X4200 M2 servers.
